Big Creek, Florence Lake Dam

Description
Big Creek, Florence Lake Dam - One of the four 1.5" diameter drains through the arch approximately 1' above the lower horizontal key before covering with facing steel. Pipes were sulfured and grouted in. 1.5" iron stop cocks were placed on the downstream ends of the pipes.
Type
Visual Materials(Opens in new tab)
Date
5/20/1942
Call number
photCL SCE 02 - 24703
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)

You might also be interested in

  • Big Creek, Florence Lake Dam

    Big Creek, Florence Lake Dam

    Visual Materials

    Big Creek, Florence Lake Dam - Close-up of 9" sealing plate in lower horizontal key after guniting in place. Plate is imbedded 6.5" in gunite. The 12' lengths of plate were electrically butt welded at the ends before guniting.

    photCL SCE 02 - 24702

  • Big Creek, Florence Lake Dam - Underneath center arch, downstream side

    Big Creek, Florence Lake Dam - Underneath center arch, downstream side

    Visual Materials

    Big Creek, Florence Lake Dam - Underneath center arch, downstream side - River Section. [showing outlets of sluice pipes]

    photCL SCE 02 - 12814

  • Big Creek, Florence Lake Dam

    Big Creek, Florence Lake Dam

    Visual Materials

    Big Creek, Florence Lake Dam - Whitmore strain gage to make rib shortening measurements on arch, also leads from two resistance thermometers grouted into area.

    photCL SCE 02 - 43636

  • Big Creek General - Florence Lake Dam

    Big Creek General - Florence Lake Dam

    Visual Materials

    Big Creek General - Florence Lake Dam - typical grouted joint repair A.B.49

    photCL SCE 02 - 28159

  • Big Creek, Vermilion Dam

    Big Creek, Vermilion Dam

    Visual Materials

    Big Creek, Vermilion Dam - Fill over toe drains downstream.

    photCL SCE 02 - 44310

  • Big Creek, Vermilion Dam

    Big Creek, Vermilion Dam

    Visual Materials

    Big Creek, Vermilion Dam - Fill over conduit and downstream Toe Drains.

    photCL SCE 02 - 44336
